Encoder WDGI 58B-10-50-ABN-G24-S2

Encoder WDGI 58B-10-50-ABN-G24-S2

WDGI 58B
Shaft Encoder incremental,
Resolution: up to 25000 ppr,
Clamping flange: Ø 58 mm [2.283"]

Shaft Ø: 10 mm [0.394"],
on request Ø: 7 mm [0.2761"], 8 mm [0.315"],
12 mm [0.472"] ,
Protection rating: up to IP67 all around,
Signal shape: square-wave or sine/cosine,
Operating principle: optical.

Mobile working machines
Measurement of the steering angle of the passenger bridge undercarriage

Capture of fork motions of a forklift truck

Lifting platform

Wind energy
Blade angle monitoring

Pitch motor control

Azimuth motor control

Cranes
Adjustment of the container spreader to different container sizes

Positioning of a crane boom

Positioning of stabilisers and booms on mobile cranes

Aerial rescue vehicles
Detection of the position and angle of a turntable ladder

Precise extension of a turntable ladder with the assistance of a Draw-wire system

Automated guided vehicle
Reliable speed monitoring AGV

Exact positioning of the fork

Detection of the steering angle of an AGV

Industrial automation
Setting the correct press stroke

Speed control for a conveyor belt

Coordination of the bottle supply

Monitoring the speed of the winding head

Heavy Industry
Bucket wheel excavator

Position and speed detection of bulk goods wagons

Wagon tippler

Detection of the rotational speed in rolling mills

Markers and labeling machines
Marking

Labeling bottles
